The Soniq Aqua by ColorJet is a 3.2-meter high-quality solvent printer designed for both indoor and outdoor signage production. Equipped with 4 or 8 high-speed Konica Minolta Aqua print heads, it delivers exceptional print quality at speeds up to 2130 sq. ft/hr.
Its advanced features streamline workflows and boost productivity, making it an ideal solution for large-format print businesses. With a maximum resolution of 1440 dpi and compatibility with various media types, the Soniq Aqua ensures vibrant and durable prints for diverse applications.
The Neptune Plus utilizes industrial-grade jetting assemblies with options for 4 or 8 print heads. This configuration enables impressive printing speeds of up to 753 sq. ft/hr, ensuring efficient production for large-scale projects.
With a maximum resolution of up to 1440 dpi, the machine delivers sharp, vibrant prints suitable for various outdoor applications, including banners, hoardings, and vehicle wraps.
The printer features an extended bed space with a conductive heater, enhancing media contact and reducing heat loss. Additionally, its advanced feed system ensures smooth media movement, minimizing issues like media sticking or misalignment.
The Neptune Plus boasts a sleek design complemented by an inbuilt LED monitor. This integration eliminates the need for external attachments, streamlining operations and enhancing the machine
Introducing the SoniQ Aqua, a game-changing 3.2-meter HQ Solvent Printer engineered to redefine the standards in both indoor and outdoor signage production.
With 4/8 high-speed KM heads, it offers unmatched upgradability, ensuring future-proof performance. Delivering stunning quality at 2130 sqft. /hr (8 Heads), it's perfect for indoor and outdoor needs. Its features streamline workflows and boost productivity, making it the ultimate solution for large format print businesses.
SONIQ AUQA |
|||||
| Model |
SC4428 |
SC8428 |
|||
| Printing Technology |
Drop-on-demand, Piezo electric inkjet |
||||
| Print Heads |
Konica Minolta Aqua |
||||
| No. of Print Heads |
4 |
8 |
|||
| Media | Width |
3300 mm (129 in.) |
|||
| Thickness |
Maximum 3.0 mm (120 mil )with liner (flexible) |
||||
| Roll Outer Diameter |
Maximum 300mm (12inch), 50.8 (2 in) |
||||
| Roll Weight |
Maximum 90 kgs |
||||
| Core Diameter |
76.2mm (3 inch) |
||||
| Types |
SAV, PAV Banner, Backlite Film, Window Film, Fabric (Solvent Base) |
||||
| Printing Width |
Maximum 3200mm (126 inch.) |
||||
| Inks | Types |
Solvent/Mild Solvent inks |
|||
| Color |
4 Colors (CMYK) |
||||
| Printing Resolution (dots per inch) |
Maximum up to 1440 dpi |
||||
| Distance Accuracy |
Error of less than ±0.3 % of distance travelled, or ±0.3 mm, whichever is greater |
||||
| Media Heating System |
Pre-heater and post-heater, setting range for the preset temprature: 30 to 60?. Dryer setting range for the preset temperature : 30 to 60? |
||||
| Connectivity |
High speed USB 3.0 or more |
||||
| Power Requirements (Peak) |
AC 220 V ±10%, 20 A, 50/60 Hz |
||||
| Dimensions ( Printer only) |
4689mm X 1079mm X 1571mm(WxLxH) |
||||
| RIP Software |
ColorJet Edition RIP |
||||
| Weight |
Net Weight : 550 KG, Gross Weight : 742 KG |
||||
| Environmental | Power ON |
Temperature: 18 to 28? Humidity: 20 to 40%RH (non-condensing) |
|||
| Power OFF |
Temperature: 5 to 40? Humidity: 20 to 80%RH (non-condensing) |
||||
| Speed (In Sq. Meter/Hrs) |
Print DPI |
Passes |
Sq Mtrs/Hr (4 Heads) |
Sq Feet/Hr (8 Heads) |
|
| Mode 1 |
540x720 |
2 |
1050 |
2130 |
|
| Mode 2 |
540x1080 |
3 |
700 |
1410 |
|
| Mode 3 |
540x1440 |
4 |
525 |
1050 |
|
| Mode 4 |
540x1080 |
6 |
350 |
700 |
|
| Mode 5 |
540x1440 |
8 |
260 |
500 |
|
